GENERAL LED DIMMER

This dimmer features smooth and noiseless dimming. It is a popular choice for those who want a straightforward and reliable option for controlling their lighting. This dimmer is compatible with most types of LED lamps and can be easily installed in just a few steps.

Model No.		D621R2
Description		General LED Dimmer
Input Voltage		220-240V
Input frequency		50Hz
Load	LED	5-250W
	Incandescent	5-300W
	Halogen	5-300W
Dimming mode		Trailing edge
Control Way		Two way
Material	Heatsink	Aluminum
	Bottom Case	PC
Color		White
Weight(g)		47
Dimension(mm)		707041.4mm

Back to list

Model No.		D621R2
Description		General LED Dimmer
Input Voltage		220-240V
Input frequency		50Hz
Load	LED	5-250W
	Incandescent	5-300W
	Halogen	5-300W
Dimming mode		Trailing edge
Control Way		Two way
Material	Heatsink	Aluminum
	Bottom Case	PC
Color		White
Weight(g)		47
Dimension(mm)		707041.4mm

/Uploads/file/20241028/20241028211311_67090.pdf

Download Center

To know further details of this product, please download the following user manual.
